LASmoons: Alex S. Olpenda

Alex S. Olpenda (recipient of three LASmoons)
Department of Geomatics and Spatial Planning, Faculty of Forestry
Warsaw University of Life Sciences, POLAND

Background:
The Bialowieza Forest is a trans-boundary property along the borders of Poland and Belarus consisting of diverse Central European lowland forest covering a total area of 141,885 hectares. Enlisted as one of the world’s biosphere reserves and a UNESCO World Heritage Site, the Bialowieza Forest conserves a complex ecosystem that supports vast wildlife including at least 250 species of birds and more than 50 mammals such as wolf, moose, lynx and the largest free-roaming population of the forest’s iconic species, the European bison [1]. The area is also significantly rich in dead wood which becomes a home for countless species of mushrooms, mold, bacteria and insects of which many of them are endangered of extinction [2]. Another factor, aside from soil type, that impacts the species of plant communities growing in the area is humidity [3] which can be considered as a function of solar radiation. Understanding the interactions and dynamics of these elements within the environment is vital for proper management and conservation practices. Sunlight below canopies is a driving force that affects the growth and survival of both fauna and flora directly and indirectly. Measurement and monitoring of this variable is crucial.

The European bison  (image credit to Frederic Demeuse).

Goal:
Remote sensing technology can describe the light condition inside the forest with relatively high spatial and temporal resolutions at large scale. The goal of this research is to develop a predictive model to estimate sub-canopy light condition of Bialowieza Forest inside Poland’s territory using LiDAR data. Aside from common metrics based on heights and intensities, extraction of selected metrics known to infer transmitted light are also to be done. Returns that belong or are close to the ground are a good substitute for sun-rays that reach the forest floor while vegetation-classified returns could be assumed as the ones impeding the light. Relationships between these metrics and to both direct and diffuse sunlight derived from hemispherical photographs will be explored. Furthermore, multiple regression shall then be conducted between the parameters. Previous similar studies have been done successfully but mostly in homogeneous forest. The task might pose a challenge as Bialowieza Forest is a mixture of conifers and broad-leaved trees.

Location map of the study site with 100 random sample plots.

Data:
+
2015 ALS data set obtained using full waveform sensor (Riegl LMS-Q680i)
+ discrete point clouds (average pulse density: 6 points/m²)
+ 134 flightlines with 40% overlap
+ forest inventory data (100 circular plots, 12.62 m radius)
+ colored hemispherical photographs
All of this data is provided by the Forest Research Institute through the ForBioSensing project.

LAStools processing:
1) data quality checking [lasinfo, lasoverlap, lasgrid, lasreturn]
2) merge and clip the LAZ files [las2las]
3) classify ground and non-ground points [lasground]
4) remove low and high outliers [lasheight, lasnoise]
5) create a normalized point cloud [lasheight]
6) compute forestry metrics for each plot [lascanopy]

References:
[1] UNESCO. World Heritage List. Available online (accessed on 2 October 2017).
[2] Polish Tourism Organization. Official Travel Website. Available online (accessed on 3 October 2017).
[3] Bialowieza National Park. Available online (accessed on 3 October 2017).
